Manufacturer:General Electric
Model:DS3800NHVE
Category:High Voltage Card
Compatibility:For use with Mark IV systems
Drilling:Double-drilled in each corner
Connectors:Multi-pin communication connectors (2) on the left edge
Markings:Alignment marks on two edges
Labels:Marked 6BA01 and 6DA01
Dimensions:To be confirmed (Refer to datasheets for precise measurements)
The DS3800NHVE, designed by GE, is a high voltage card tailored specifically for the Mark IV series, ideal for steam or gas turbine management. It boasts multiple features that enhance operational efficiency and reliability. The card is equipped with dual drilling in each corner for secure mounting. Additionally, it includes two multi-pin communication connectors positioned on the left side, facilitating seamless connectivity.
The DS3800NHVE is marked for precise alignment on two edges, ensuring accurate installation. Its design includes five jumper switches that can be set to either H or B positions, providing flexibility for various applications. On the right side, there are five 2-pin four-position headers, enhancing the card’s functionality. Moreover, it features six contact points, enabling effective electrical connections.
This high voltage card is labeled with the codes 6BA01 and 6DA01, making identification straightforward. Detailed installation guidelines and safety procedures are included in manuals, ensuring safe and efficient operation. The DS3800NHVE is a testament to GE’s commitment to quality and innovation in industrial control systems.
